We utiize NO-DIG technology, which was developed based on NTT's R & D results, to continue to take part in improving social infrastructure efficiency, as well as to contributing to global environmental protection.
Check inExams a continuous and fast appearance on the web print.
■Image processing apparatus of the original development is the automatic follow-up to the transfer speed, and high-speed inspection.
■The multiple registration of the reference image, I realize the inspection allows the variation of non-defective product.
■"line block position correction" function, can be inspected with high accuracy.
■It is equipped with a dedicated garbled detection algorithm.
■Inspection analysis system "VST" (optional), it can understand the position information of the defective part.
■The maintenance services to be remotely connected using a communication line to allow the quick response of the trouble occurs.
| Target Work | Web-print |
|---|---|
| Work Shape | Width：300mm |
| Processing Time | 150m/minute |
| Defect detection capability | • Flying ink, ink stains • Color irregularities, poor color tone • Garbled, smudged characters • Pinball |
| Minimum defect size | 0.3mm or more |
※Processing time, minimum defect size can be changed according to the specifications.
| Target Work | (Cosmetics, pharmaceutical, etc.) beverage cans, plastic containers |
|---|---|
| Processing Time | 120～300 bottles / minute |
| Defect detection capability | • Dirt • Printing Defects • Contamination • (Unevenness, scratches) deformation |
| Minimum Defect Size | Φ0.3mm or more |
※ Processing time, minimum defect size can be changed according to the specifications.
